CNC Profile Router Bits

WORKINGS
Contouring
Internal milling
Profile
PERFORMANCES
Drawings and Specs Chart
Technical drawings

TYPE A
TYPE B
TYPE C
TYPE D
TYPE E
TYPE F
TYPE A PCD PLUNGE CUT

Table
2602020 2602021 28 19 50 87 20 2+1 4
2602020 2602021 28 19 50 87 20 2+1 4
2602022 2602023 28 26 50 94 20 2+1 4
2602022 2602023 28 26 50 94 20 2+1 4
2602024 2602025 28 19 55 91 25 2+1 4
2602024 2602025 28 19 55 91 25 2+1 4
2602026 2602027 28 26 55 99 25 2+1 4
2602026 2602027 28 26 55 99 25 2+1 4
TYPE B

Table
2603020 2603021 30 19 50 87 20 2 4
2603020 2603021 30 19 50 87 20 2 4
2603022 2603023 30 26 50 94 20 2 4
2603022 2603023 30 26 50 94 20 2 4
2603024 2603025 30 19 50 92 20 2 4
2603024 2603025 30 19 50 92 20 2 4
2603026 2603027 30 26 50 99 20 2 4
2603026 2603027 30 26 50 99 20 2 4
TYPE C

Table
2600020 2600021 40 16 50 85 20 2 4
2600020 2600021 40 16 50 85 20 2 4
2600022 2600023 42 18 50 87 20 2 4
2600022 2600023 42 18 50 87 20 2 4
2600024 2600025 44 20 50 89 20 2 4
2600024 2600025 44 20 50 89 20 2 4
2600026 2600027 48 24 50 93 20 2 4
2600026 2600027 48 24 50 93 20 2 4
2600032 2600033 40 16 55 90 25 2 4
2600032 2600033 40 16 55 90 25 2 4
2600034 2600035 42 18 55 92 25 2 4
2600034 2600035 42 18 55 92 25 2 4
2600036 2600037 44 20 55 94 25 2 4
2600036 2600037 44 20 55 94 25 2 4
2600038 2600039 48 24 55 98 25 2 4
2600038 2600039 48 24 55 98 25 2 4
TYPE D PCD PLUNGE CUT

Table
2601020 2601021 28 23 50 87 20 2+1 4
2601020 2601021 28 23 50 87 20 2+1 4
2601022 2601023 30 23 50 87 20 2+1 4
2601022 2601023 30 23 50 87 20 2+1 4
2601024 2601025 32 23 50 87 20 2+1 4
2601024 2601025 32 23 50 87 20 2+1 4
2601026 2601027 34 23 50 87 20 2+1 4
2601026 2601027 34 23 50 87 20 2+1 4
2601028 2601029 38 23 50 87 20 2+1 4
2601028 2601029 38 23 50 87 20 2+1 4
2601034 2601035 52 23 50 87 20 2+1 4
2601034 2601035 52 23 50 87 20 2+1 4
2601036 2601037 28 23 55 92 25 2+1 4
2601036 2601037 28 23 55 92 25 2+1 4
2601038 2601039 30 23 55 92 25 2+1 4
2601038 2601039 30 23 55 92 25 2+1 4
2601040 2601041 32 23 55 92 25 2+1 4
2601040 2601041 32 23 55 92 25 2+1 4
2601042 2601043 34 23 55 92 25 2+1 4
2601042 2601043 34 23 55 92 25 2+1 4
2601044 2601045 38 23 55 92 25 2+1 4
2601044 2601045 38 23 55 92 25 2+1 4
TYPE E

Table
2604020 2604021 24 8 50 76 20 2 4
2604020 2604021 24 8 50 76 20 2 4
2604022 2604023 24 10 50 78 20 2 4
2604022 2604023 24 10 50 78 20 2 4
2604024 2604025 24 15 50 85 20 2 4
2604024 2604025 24 15 50 85 20 2 4
2604026 2604027 24 19 50 89 20 2 4
2604026 2604027 24 19 50 89 20 2 4
TYPE F

Table
2605020 2605021 28 16 50 80 20 2 4
2605020 2605021 28 16 50 80 20 2 4
2605022 2605023 30 16 50 80 20 2 4
2605022 2605023 30 16 50 80 20 2 4
2605024 2605025 28 20 50 84 20 2 4
2605024 2605025 28 20 50 84 20 2 4
2605026 2605027 30 20 50 84 20 2 4
2605026 2605027 30 20 50 84 20 2 4
Applications:
Panel profiling.

Machines:
CNC Routers.

Materials:
Plastic, HPL, chipboard, MDF and plywood panels with or without veneer.

Technical Features:
Z2 configuration. Polished PCD tips Excellent cut both on panel and on finishing. PCD plunge cut available on some models. Ground shank with h6 tolerance for assembling on Hydro’s, Tribos or Heat Shrink tool holders.

Re-sharpening:
up to 6 times
Contact us for a quote
